Features

Offering Great Advantages

Toyota's special box forklift features Toyota's Active Stability System (SAS), ™ which automatically detects potentially unsafe conditions and activates additional safety features to increase operator protection and reduce damage to the product and forklift. The force-cooled wet disc brakes found in the Box Car Special will reduce maintenance costs and downtime with an expected life of 10 years/20,000 hours*. This forklift comes with a tighter turning radius, an economy mode option (ECO), and an active mast function controller, all of which increase productivity and control when in operation.

Designed for the Daily Operator

Toyota's special wagon forklift comes with improved ergonomics, including load-sensing power steering, 11.8" steering wheel, in-dash courtesy tray and an oversized cup holder. This forklift also has a dash-mounted instrument display, low and wide entry steps, and a standard 4-way adjustable vinyl full suspension seat that is wider with no hip restrictions for easier entry/exit than competing seats. The seat also provides adjustable weight for greater operator comfort.

Think Inside the Box

The Toyota Box Car Special is a purpose-built adaptation of the Large IC Cushion forklift, engineered specifically for tight, confined environments. Its vertically extended compact counterweight allows operators to maneuver confidently inside rail cars, trailers, and other restricted spaces without compromising lifting power. This smart, space-saving design expands what’s possible in rack fitting, warehouse layout, and shipping workflows—letting your operation think both big and small at the same time.

Specifications

For more detailed, product specific specification data, select an individual model number from the chart below.

Model Load Capacity (lbs./kgs.) Maximum Travel Speed - Full Load (mph) Lifting Speed - Full Load (fpm) Gradeability - Maximum - Full Load Basic Right-Angle Stacking Aisle Width (in.)
50-8FGC35U-BCS 8000 (3500) 11.8 (19) 100 (510) 47 100.5 (2560)
50-8FGC45U-BCS 10000 (4500) 11.8 (19) 98 (500) 37 106.5 (2710)
50-8FGC55U-BCS 12000 (5500) 13 (21) 91 (460) 34 112 (2850)

Performance Data

Load Capacity (lbs./kgs.)

8000 (3500)

Maximum Travel Speed - Full Load (mph)

11.8 (19)

Lifting Speed - Full Load (fpm)

100 (510)

Gradeability - Maximum - Full Load

47

Basic Right-Angle Stacking Aisle Width (in.)

100.5 (2560)

Load Capacity (lbs./kgs.)

10000 (4500)

Maximum Travel Speed - Full Load (mph)

11.8 (19)

Lifting Speed - Full Load (fpm)

98 (500)

Gradeability - Maximum - Full Load

37

Basic Right-Angle Stacking Aisle Width (in.)

106.5 (2710)

Load Capacity (lbs./kgs.)

12000 (5500)

Maximum Travel Speed - Full Load (mph)

13 (21)

Lifting Speed - Full Load (fpm)

91 (460)

Gradeability - Maximum - Full Load

34

Basic Right-Angle Stacking Aisle Width (in.)

112 (2850)
