Specifications
General Data
Load Capacity (lbs./kgs.)
3000 (1350)
Load Center
24 (600)
Power Type
Battery
Operator Position
Seated Rider
Tire Type
Solid Pneumatic
Wheels (x=driven)
2x/2
Exterior Dimensions
Maximum Fork Height (MFH) (in.)
118 (3000)
Free-Lift (in.)
5.7 (145)
Fork Size (T x W x L) (in.)
1.4 x 4 x 42 (35 x 100 x 1070)
Fork Spread Max. / Min. (in.)
8 (200) / 36 (920)
Tilt Range (deg)
7 / 11
Length to Fork Face (in.)
81.9 (2080)
Overall Width (in.)
43.9 (1115)
Mast Lowered Height (in.)
77.6 (1970)
Mast Extended Height (in.)
166.1 (4220)
Overhead Guard Height (in.)
82.9 (2105)
Turning Radius (in.)
69.7 (1770)
Load Distance (in.)
15.9 (405)
Basic Right-Angle Stacking Aisle Width (in.)
85.6 (2175)
Performance
Maximum Travel Speed - Full Load (mph)
9 (14.5)
Maximum Travel Speed - No Load (mph)
10.6 (17)
Lifting Speed - Full Load (fpm)
83 (420)
Lifting Speed - No Load (fpm)
128 (650)
Lowering Speed - Full Load (fpm)
98 (500)
Lowering Speed - No Load (fpm)
108 (550)
Drawbar Pull - Max. - Full Load (fpm)
615 (280)
Drawbar Pull - Max. - No Load (fpm)
615 (280)
Gradeability - Maximum - Full Load
12
Gradeability - Maximum - No Load
19
Truck Weights
Total Weight (lb.)
4750 (2155 without battery)
Weight Distribution - Full Load (front / rear) - (lb.)
8640 / 1280
Weight Distribution - No Load (front / rear) - (lb.)
3220 / 3400
Tires
Number (front / rear)
2/2
Size - Front
6-9-10PR
Size - Rear
5-8-8PR
Wheelbase (in.)
55.5 (1410)
Tread Width - Front (in.)
37.8 (960)
Underclearance - Minimum with Load (in.)
2.6 (65)
Underclearance -Center of Wheelbase (in.)
3.3 (85)
Brake - Service / Parking
Hydraulic / Hand
Tread Width - Rear (in.)
35.2 (895)
Power System
Battery (6-hour rating) (V/Ah)
48 / 545
Auxiliary Hydraulic Function Specifications
Max. Operating Pressure (psi)
1700 (120)
Battery Features
Electric Motors - Drive (60 minutes) (hp)
10.2 (7.6)
Control Type
Transistor Invertor
