Model 8FBA20U

3,000-5,000 lb. Lifting Capacity

Toyota's Stand-Up Rider sets the standard for performance, efficiency, and operator comfort. Designed for loads up to 5,000 lbs. and engineered to handle higher capacities at greater heights, this solution thrives in demanding warehouse environments. Its compact design and 270-inch lift height allow it to navigate narrow aisles with ease, enabling you to store more products in your facility. Electric power steering reduces operator effort and fatigue, allowing for confident handling. Toyota's Stand-Up Rider Counterbalance Forklift is a multi-purpose forklift that is ready to work when you are.

Apply For Financing Request A Quote

Request Rental Quote

Features

Specifications

General Data

Power Type

Battery

Operator Position

Stand-Up Rider

Tire Type

Solid Rubber / Polyurethane

Wheels (x=driven)

2x / 2

Load Capacity (lbs./kgs.)

4000

Load Center

24 (600)

Auxiliary Hydraulic Function Specifications

Max. Operating Pressure (psi)

2200

Maximum Flow Rate (gpm)

3 - 10

Exterior Dimensions

Maximum Fork Height (MFH) (in.)

258.5

Free-Lift

Fork Size (T x W x L)

42 x 1.5 x 4

Fork Spread Max. / Min.

33.45 / 13

Tilt Range

3 / 5

Length to Fork Face

76.1

Mast Lowered Height

107

Mast Extended Height

307

Overhead Guard Height

Turning Radius

60.5

Load Distance

14.2

Basic Right-Angle Stacking Aisle Width

74.5

Chassis Height (lowered)

50.5

Underclearance (lowered)

4.1

Performance

Lifting Speed - Full Load (fpm)

Lifting Speed - No Load (fpm)

130

Lowering Speed - Full Load (fpm)

113

Lowering Speed - No Load (fpm)

Gradeability - Maximum - Full Load

Maximum Travel Speed - Full Load (mph)

Maximum Travel Speed - No Load (mph)

Truck Weights

Total Weight (lb.)

7545

Tires

Size - Front

16.25 x 7

Size - Rear

10 x 5 x 6.5

Wheelbase (in.)

53.1

Brake - Service / Parking

Plugging / Electric Disc Brake

Grade Clearance (%)

38.7

Power System

Battery (5-hour rating) (V/Ah)

36 / 1240

Battery Type

Lead Acid

Battery Features

Battery Compartment Width (in.)

38.5

Battery Weight Minimum (lb.)

2300

Electric Motors - Drive (60 minutes) (hp)

Control Type

Transistor - MOSFET
