Features
Specifications
General Data
Power Type
Battery
Operator Position
Walkie
Tire Type
Polyurethane
Wheels (x=driven)
1 Drive, 2 Load / 2 Caster
Bumper Underclearance (in.)
1.8 (45)
Load Capacity (lbs./kgs.)
4500 (2045)
Exterior Dimensions
Overall Width
27 (685)
Turning Radius
52.6 (1336)
Basic Right-Angle Stacking Aisle Width
N/A
Fork Length (in.)
45.3 (1150)
Overall Length (in.)
60.5 (1536)
Fork Width (in.)
6.3 (160)
Distance from Bumper to Center of Drive Tire (in.)
5.7 (144)
Performance
Lifting Speed - Full Load (fpm)
0.04 (12)
Lifting Speed - No Load (fpm)
0.06 (19)
Gradeability - Maximum - Full Load
7
Gradeability - Maximum - No Load
16
Maximum Travel Speed - Full Load (mph)
2.7 (4.4)
Maximum Travel Speed - No Load (mph)
3.0 (4.8)
Tires
Number (front / rear)
1 / 2
Size - Front
8.3 x 2.8 (210 x 75)
Size - Rear
3.2 x 3.7 (80 x 93)
Wheelbase (in.)
46.8 (1189)
Battery Features
Voltage/Capacity
48
Battery Weight Minimum (lb.)
16.5 (7.5)
Electric Motors - Drive (60 minutes) (hp)
1.0 (0.75)
Control Type
DC- Speed Control
