Features
Specifications
General Data
Load Capacity (lbs./kgs.)
16400 /2400
Power Type
LP / Gas
Operator Position
Seated Rider / LH Seat
Tire Type
Cushion / Cushion
Wheels (x=driven)
2x / 2
Exterior Dimensions
Maximum Fork Height (MFH) (in.)
95
Free-Lift (in.)
22
Fork Size (T x W x L) (in.)
3.50 x 8.0 x 96
Fork Spread Max. / Min. (in.)
54.63 / 4.75
Tilt Range (deg)
11/6
Length to Fork Face (in.)
129.4 / 165.4
Overall Width (in.)
62
Mast Lowered Height (in.)
95.0
Mast Extended Height (in.)
165.0
Overhead Guard Height (in.)
86.79
Turning Radius (in.)
114.0 / 147.0
Load Distance (in.)
26.4
Basic Right-Angle Stacking Aisle Width (in.)
140 - 173
Maximum Boom Lifting Height (in.)
264.0
Maximum Boom Extension Length (in.)
96.0
Performance
Maximum Travel Speed - Full Load (mph)
23
Lifting Speed - Full Load (fpm)
23
Truck Weights
Total Weight (lb.)
33910
Weight Distribution - Full Load (front / rear) - (lb.)
53040 / 16260
Weight Distribution - No Load (front / rear) - (lb.)
12280 / 21630
Tires
Number (front / rear)
2 / 2
Size - Front
28 X 16 X 22
Size - Rear
22 X 8 X 16
Wheelbase (in.)
76.0 / 112.0
Tread Width - Front (in.)
48.63
Underclearance - Minimum with Load (in.)
4.0
Underclearance -Center of Wheelbase (in.)
4.75
Brake - Service / Parking
Hydrostatic / Mechanical
Tread Width - Rear (in.)
47.9
Power System
Engine Make / Model
PSI 2.4L
Rated Horsepower @ rpm (SAE HP)
63.2 @ 2800
Rated Torque @ rpm (SAE HP)
123.9 @ 1600
Number of Cylinders
4
Transmission Type
Hydrostatic
Transmission Speeds (forward / reverse)
2 / 2
Max. Operating Pressure (psi)
2500
Max. Flow Rate (gpm)
24.2
