Features
Specifications
General Data
Load Capacity (lbs./kgs.)
35200 / 51900
Power Type
LP / Gas
Operator Position
Seated Rider / LH Seat
Tire Type
Cushion / Cushion
Wheels (x=driven)
2x / 2
Exterior Dimensions
Maximum Fork Height (MFH) (in.)
104.50
Free-Lift (in.)
31.00
Fork Size (T x W x L) (in.)
4.50 (114.3) x 10.00 (254) x 96.00
Fork Spread Max. / Min. (in.)
65.38 (1660.7) / 6.63
Tilt Range (deg)
12/7
Length to Fork Face (in.)
154.44 (3922.8) / 202.44
Overall Width (in.)
72.00
Mast Lowered Height (in.)
107.00
Mast Extended Height (in.)
175.75
Overhead Guard Height (in.)
92.81
Turning Radius (in.)
140.0 (3556.0) / 185.0
Load Distance (in.)
28.94
Basic Right-Angle Stacking Aisle Width (in.)
168.90 (4290) / 213.9
Maximum Boom Lifting Height (in.)
306.31
Maximum Boom Extension Length (in.)
120.00
Truck Weights
Total Weight (lb.)
58860
Weight Distribution - Full Load (front / rear) - (lb.)
112200 / -
Weight Distribution - No Load (front / rear) - (lb.)
- / 32000
Tires
Number (front / rear)
4 / 2
Size - Front
28 X 10 X 22
Size - Rear
28 X 10 X 22
Wheelbase (in.)
98.0 (2489.2) / 146.0
Tread Width - Front (in.)
52
Underclearance - Minimum with Load (in.)
4.5
Underclearance -Center of Wheelbase (in.)
6.5
Brake - Service / Parking
Hydrostatic / Mechanical
Tread Width - Rear (in.)
60
Power System
Engine Make / Model
GM 3.0L
Rated Horsepower @ rpm (SAE HP)
81 @ 3000
Rated Torque @ rpm (SAE HP)
149 @ 2000
Number of Cylinders
4
Transmission Type
Hydrostatic
Transmission Speeds (forward / reverse)
2 / 2
