Features
Specifications
General Data
Power Type
Battery
Operator Position
Center-Controlled Rider
Tire Type
Rubber / Polyurethane
Wheels (x=driven)
1 / 2
Bumper Underclearance (in.)
2.1 (53)
Load Capacity (lbs./kgs.)
2500 (1134)
Exterior Dimensions
Overall Width
33.25 (845)
Mast Lowered Height
61 (1549)
Mast Extended Height
113 (2870)
Turning Radius
69.8 (1773)
Fork Length (in.)
42 (1067)
Overall Length (in.)
121 (3073)
Fork Width (in.)
4 (102)
Power Unit Height
38 (965)
Distance from Bumper to Center of Drive Tire (in.)
13.3 (338)
Platform Height (in.)
8.3 (211)
Performance
Lifting Speed - Full Load (fpm)
22 (0.11)
Lifting Speed - No Load (fpm)
41 (0.21)
Lowering Speed - Full Load (fpm)
48 (0.24)
Lowering Speed - No Load (fpm)
44 (0.22)
Gradeability - Maximum - Full Load
8
Gradeability - Maximum - No Load
8
Maximum Travel Speed - Full Load (mph)
6.0 (9.6)
Maximum Travel Speed - No Load (mph)
3.8 (6.1)
Tires
Wheelbase (in.)
55.7 (1415)
Brake - Service / Parking
Electric Disc Brake
Battery Features
Voltage/Capacity
24 / 750
Battery Compartment Width (in.)
13.4 (340)
Battery Weight Maximum (lb.)
1500 (680)
Battery Weight Minimum (lb.)
1300 (590)
Electric Motors - Drive (60 minutes) (hp)
4.4 (3.3)
