Features

Heavy Duty Stacking Capabilities

Toyota’s Counter-Balanced Stacker goes where others fear to stack. This lift is capable of lifting wide loads while operating seamlessly in aisles that are too narrow for traditional sit-down forklifts. Warehouse navigation is now simplified. With a 24-Volt Electrical System, ergonomic control handle, and 30-inch wide ITA Class II Hook-Type Carriage, the Counter-Balanced Stacker can be an asset to your company for years to come.

Special Features
Quality, Durability, & Value

Toyota’s Counter-Balanced Stacker is only 32.5 inches wide but can lift up to 189 inches and can store and stack loads weighing up to 4,000 pounds. This product comes with an easy-to-operate, multifunction control handle to ensure the operator is comfortable and productive shift after shift. The Counter-Balanced Stacker also has an easy access service cover for smooth and easy maintenance.

Key Safety Features

Safety features on the Counter-Balanced Stacker include a high-visibility mast that allows the operator to clearly see fork tips and a wider work area. This forklift also includes an emergency power disconnect switch that protects both the operator and the cargo being handled by instantly powering off the forklift in a time of need.

Specifications

For more detailed, product specific specification data, select an individual model number from the chart below.

Model Load Capacity (lbs./kgs.) Maximum Travel Speed - Full Load (mph) Lifting Speed - Full Load (fpm) Basic Right-Angle Stacking Aisle Width (in.)
WS1-CB20 2000 (907) 3.5 (5.6) 37 (188) 91
WS1-CB30 3000 (1360) 3.5 (5.6) 32 (163) 96
WS1-CB40 4000 (1814) 3.5 (5.6) 27 (137) 102

Performance Data

Model

WS1-CB20

Load Capacity (lbs./kgs.)

2000 (907)

Maximum Travel Speed - Full Load (mph)

3.5 (5.6)

Lifting Speed - Full Load (fpm)

37 (188)

Basic Right-Angle Stacking Aisle Width (in.)

91

Model

WS1-CB30

Load Capacity (lbs./kgs.)

3000 (1360)

Maximum Travel Speed - Full Load (mph)

3.5 (5.6)

Lifting Speed - Full Load (fpm)

32 (163)

Basic Right-Angle Stacking Aisle Width (in.)

96

Model

WS1-CB40

Load Capacity (lbs./kgs.)

4000 (1814)

Maximum Travel Speed - Full Load (mph)

3.5 (5.6)

Lifting Speed - Full Load (fpm)

27 (137)

Basic Right-Angle Stacking Aisle Width (in.)

102
