Features
Specifications
General Data
Power Type
Battery
Operator Position
Seated Rider
Tire Type
Cushion
Wheels (x=driven)
1x / 2
Load Capacity (lbs./kgs.)
3500
Load Center
24 (600)
Exterior Dimensions
Maximum Fork Height (MFH) (in.)
433.1
Free-Lift
129.1
Fork Size (T x W x L)
1.57 x 4 x 45.28 ( 40 x 100 1150)
Tilt Range
2 / 4
Length to Fork Face
58.6
Overall Width
50-57.9
Mast Lowered Height
166.2
Mast Extended Height
472.4
Overhead Guard Height
86.5
Turning Radius
65.2
Lowered Height (in.)
2.2
Performance
Lifting Speed - Full Load (fpm)
74.8
Lifting Speed - No Load (fpm)
133.9
Lowering Speed - Full Load (fpm)
108.3
Lowering Speed - No Load (fpm)
116.1
Gradeability - Maximum - Full Load
10
Gradeability - Maximum - No Load
15
Maximum Travel Speed - Full Load (mph)
6.2
Maximum Travel Speed - No Load (mph)
6.8
Truck Weights
Total Weight (lb.)
5982
Tires
Size - Front
13.5 x 5.5
Size - Rear
11.8 x 4.2
Wheelbase (in.)
54.9
Underclearance -Center of Wheelbase (in.)
2.9
Brake - Service / Parking
Electric Disc
Power System
Battery Type
Lead Acid
Battery Features
Voltage/Capacity
48 / 930
Battery Weight Maximum (lb.)
3175
Battery Weight Minimum (lb.)
2756
Electric Motors - Drive (60 minutes) (hp)
12.1
Control Type
AC
