Features
Specifications
General Data
Load Capacity (lbs./kgs.)
59500
Power Type
Electric
Operator Position
Seated Rider
Tire Type
Pneumatic
Wheels (x=driven)
2 / 2x
Maximum Drawbar
5500 (2500)
Exterior Dimensions
Overall Width (in.)
56.9 (1445)
Turning Radius (in.)
126 (3200)
Overall Length (with attachment) (in)
137.6 (3495)
Overall Length (in.)
128.5 (3265)
Underclearance (lowered)
5.9 (150)
Performance
Maximum Travel Speed - No Load (mph)
15.5 (25)
Gradeability - Maximum - Full Load
33
Truck Weights
Total Weight (lb.)
10515 (4770 with battery)
Tires
Number (front / rear)
2 / 2
Size - Front
175R13-8PR (LT)
Size - Rear
28 x 8-15-12PR (I)
Wheelbase (in.)
88.2 (2240)
Tread Width - Front (in.)
48.2 (1225)
Brake - Service / Parking
Tandem Hydraulic / Mechanical-Double Action
Tread Width - Rear (in.)
46.9 (1190)
Battery Features
Voltage/Capacity
80
Control Type
Transistor Inverter
