Features
Specifications
General Data
Load Capacity (lbs./kgs.)
8800 (4000)
Power Type
Battery
Operator Position
Stand-Up Rider Tow Tractor
Tire Type
Solid Pneumatic
Wheels (x=driven)
2 / 2x
Exterior Dimensions
Overall Width (in.)
38 (965)
Turning Radius (in.)
63 (1600)
Overall Length (with attachment) (in)
69.1 (1755)
Overall Length (in.)
63.6 (1615)
Underclearance (lowered)
3 (75)
Performance
Drawbar Pull - Continuous (lb.)
220 (100)
Maximum Travel Speed - Full Load (mph)
5.6 (9) with 4400 lbs. (2000 kg)
Maximum Travel Speed - No Load (mph)
8.4 (13.5)
Gradeability - Maximum - No Load
36
Truck Weights
Total Weight (lb.)
2240 (1015 with battery)
Weight Distribution - Full Load (front / rear) - (lb.)
640 / 1600 (290 / 725)
Tires
Size - Front
3.5-5 (90-127)
Size - Rear
4-8 (100-200)
Wheelbase (in.)
44.9 (1140)
Power System
Battery (6-hour rating) (V/Ah)
48 / 220
Battery Features
Battery Weight Maximum (lb.)
950 (430 with rollers)
Electric Motors - Drive (60 minutes) (hp)
3.5 (2.6)
Control Type
Transistor Chopper
