Specifications


General Data
Power Type
Battery
Operator Position
Seated Rider
Tire Type
Pneumatic-Shaped Solid
Wheels (x=driven)
2x / 2
Load Capacity (lbs./kgs.)
4000
Load Center
24 (600)
Auxiliary Hydraulic Function Specifications
Max. Operating Pressure (psi)
3050
Exterior Dimensions
Free-Lift
60.2
Fork Size (T x W x L)
1.6 x 4.8 x 42.1
Tilt Range
5 / 6
Length to Fork Face
80
Overall Width
45.3
Overhead Guard Height
84.3
Turning Radius
63.2
Basic Right-Angle Stacking Aisle Width
130.8
Performance
Lifting Speed - Full Load (fpm)
68.9
Lifting Speed - No Load (fpm)
84.6
Lowering Speed - Full Load (fpm)
86.6
Lowering Speed - No Load (fpm)
72.8
Gradeability - Maximum - Full Load
15
Gradeability - Maximum - No Load
17
Maximum Travel Speed - Full Load (mph)
9.3
Maximum Travel Speed - No Load (mph)
9.9
Truck Weights
Total Weight (lb.)
8415
Tires
Size - Front
200/50-10
Size - Rear
15 x 4.5-8
Wheelbase (in.)
53.5
Tread Width (in.)
36.9
Underclearance -Center of Wheelbase (in.)
4.1
Brake - Service / Parking
Regenerative / Electromagnetic
Tread Width - Rear (in.)
6.9
Battery Features
Voltage/Capacity
48 / 360
