Forklifts
Big Joe Forklifts – Smart, Simple, and Built for Productivity
Integrated Lithium-Ion Forklifts
From compact electric forklifts to powerful lift trucks built for tight spaces, Big Joe offers an equipment lineup focused on doing the job—simply and effectively.Specifications
For more detailed, product specific specification data, select an individual model number from the chart below.
| Model | Turning Radius | Lifting Speed - Full Load (fpm) | Gradeability - Maximum - Full Load | Maximum Travel Speed - Full Load (mph) | Load Capacity (lbs./kgs.) |
|---|---|---|---|---|---|
| LVE35 | 61 | 65 | 10 | 8 | 3500 |
| LVE40 | 63.2 | 68.9 | 15 | 9.3 | 4000 |
| LXE40 | 81.9 | 55.1 | 10.5 | 6.5 | 4000 |
| LCE50-65S | 78.4-81.1 | 98-120 | 15-17 | 10.5-10.6 | 5000-6500 |
| LXE50 | 75.6 | 74.8 | 15 | 9 | 5000 |
| LPE50-70S | 90.8-94.7 | 78.7 | 18-20 | 9.9 | 5000-7000 |
| LPE80/LPE100S | 105.3 | 59 | 15 | 9.9 | 8000-10000 |
Performance Data
Model
LVE35Turning Radius
61
Lifting Speed - Full Load (fpm)
65
Gradeability - Maximum - Full Load
10
Maximum Travel Speed - Full Load (mph)
8
Load Capacity (lbs./kgs.)
3500
Model
LVE40Turning Radius
63.2
Lifting Speed - Full Load (fpm)
68.9
Gradeability - Maximum - Full Load
15
Maximum Travel Speed - Full Load (mph)
9.3
Load Capacity (lbs./kgs.)
4000
Model
LXE40Turning Radius
81.9
Lifting Speed - Full Load (fpm)
55.1
Gradeability - Maximum - Full Load
10.5
Maximum Travel Speed - Full Load (mph)
6.5
Load Capacity (lbs./kgs.)
4000
Model
LCE50-65STurning Radius
78.4-81.1
Lifting Speed - Full Load (fpm)
98-120
Gradeability - Maximum - Full Load
15-17
Maximum Travel Speed - Full Load (mph)
10.5-10.6
Load Capacity (lbs./kgs.)
5000-6500
Model
LXE50Turning Radius
75.6
Lifting Speed - Full Load (fpm)
74.8
Gradeability - Maximum - Full Load
15
Maximum Travel Speed - Full Load (mph)
9
Load Capacity (lbs./kgs.)
5000
Model
LPE50-70STurning Radius
90.8-94.7
Lifting Speed - Full Load (fpm)
78.7
Gradeability - Maximum - Full Load
18-20
Maximum Travel Speed - Full Load (mph)
9.9
Load Capacity (lbs./kgs.)
5000-7000
Model
LPE80/LPE100STurning Radius
105.3
Lifting Speed - Full Load (fpm)
59
Gradeability - Maximum - Full Load
15
Maximum Travel Speed - Full Load (mph)
9.9
Load Capacity (lbs./kgs.)
8000-10000
