Features
Specifications
General Data
Bumper Height (in.)
9.84 (250)
Load Capacity (lbs./kgs.)
10000 (4540)
Power Type
Battery
Operator Position
Center-Controlled Rider
Tire Type
Polyurethane
Wheels (x=driven)
1 Drive, 2 Casters / 2 Rear
Exterior Dimensions
Overall Width (in.)
39.94 (1014)
Turning Radius (in.)
55.84 (1418)
Overall Length (in.)
57.97 (1472)
Power Unit Height
32.32 (821)
Distance from Bumper to Center of Drive Tire (in.)
14.65 (372)
Bumper Underclearance (in.)
2.94 (75)
Platform Height (in.)
8.18 (208)
Platform Lift Height (in.)
15.55 (395)
Performance
Drawbar Pull - Continuous (lb.)
250 (114)
Maximum Travel Speed - Full Load (mph)
5.8 (9.3)
Maximum Travel Speed - No Load (mph)
8.8 (14.2)
Drawbar Pull - Max. - Full Load (fpm)
750 (341)
Tires
Number (front / rear)
3 / 2
Size - Front
12 x 4.75 (305 x 121)
Size - Rear
6 x 3.25 (152 x 82)
Wheelbase (in.)
37.38 (949)
Tire Size - Casters (front) (in.)
4 x 2.5 (102 x 64)
Battery Features
Voltage/Capacity
24 x 750
Connector (Color)
SB-175 (gray)
Connector Cable Location
B
Connector Cable Length (in.)
18 (457)
Battery Compartment Width (in.)
31.75 (806)
Battery Weight Maximum (lb.)
1500 (680)
Battery Weight Minimum (lb.)
980 (445)
Electric Motors - Drive (60 minutes) (hp)
5.5 (4.1)
