Features
Specifications
General Data
Power Type
LPG
Operator Position
Seated Rider
Tire Type
Cushion
Wheels (x=driven)
2x / 2
Load Capacity (lbs./kgs.)
8000 (3500)
Exterior Dimensions
Maximum Fork Height (MFH) (in.)
159.5 (4050)
Free-Lift
33.1 (840)
Fork Size (T x W x L)
2 x 6 x 42 (50 x 150 x 1070)
Fork Spread Max. / Min.
45.7 / 11.8
Tilt Range
5 / 5
Length to Fork Face
103.9 (2640)
Overall Width
55.9 (1420)
Mast Lowered Height
81.1 (2060)
Mast Extended Height
207.5 (5270)
Overhead Guard Height
83.5 (2120)
Turning Radius
90 (2280)
Load Distance
17.7 (450)
Basic Right-Angle Stacking Aisle Width
108 (2750)
Performance
Lifting Speed - Full Load (fpm)
100 (510)
Lifting Speed - No Load (fpm)
108 (550)
Lowering Speed - Full Load (fpm)
104 (530)
Lowering Speed - No Load (fpm)
94 (480)
Drawbar Pull - Max. - Full Load (fpm)
9900 (4500)
Drawbar Pull - Max. - No Load (fpm)
2580 (1170)
Gradeability - Maximum - Full Load
47
Gradeability - Maximum - No Load
19
Maximum Travel Speed - Full Load (mph)
11.8 (19)
Maximum Travel Speed - No Load (mph)
11.8 (19)
Truck Weights
Total Weight (lb.)
13730 (6240)
Weight Distribution - Full Load (lb.)
18600 / 2850
Weight Distribution - No Load (lb.)
5720 / 8010
Tires
Number (front / rear)
2 / 2
Size - Front
22 x 12 x 16
Size - Rear
18 x 6 x 12-1/8
Wheelbase (in.)
61.8 (1570)
Tread Width (in.)
43.9 (1115)
Underclearance - Minimum with Load (in.)
3.3 (85)
Underclearance -Center of Wheelbase (in.)
5.7 (145)
Brake - Service / Parking
Hydraulic / Hand
Tread Width - Rear (in.)
41.4 (1050)
Power System
Battery (5-hour rating) (V/Ah)
12 / 35
Rated Horsepower @ rpm
87 @ 2330
Rated Torque @ rpm (SAE HP)
212 @ 1500
Number of Cylinders
4
Piston Displacement (cu in)
224 (3685)
Transmission Type
Automatic
Transmission Speeds (forward / reverse)
1 / 1
Max. Operating Pressure (psi)
2630 (185)
Max. Flow Rate (gpm)
33.8 (128)
