Specifications
General Data
Power Type
Battery
Tire Type
Cushion
Load Capacity (lbs./kgs.)
3000
Exterior Dimensions
Maximum Fork Height (MFH) (in.)
119
Fork Size (T x W x L)
1.4 x 4 x 42
Tilt Range
5 / 6.5
Length to Fork Face
72
Overall Width
41.5 (42.1)
Mast Lowered Height
77.6
Mast Extended Height
167.5
Overhead Guard Height
81
Turning Radius
58.3
Load Distance
13.8
Basic Right-Angle Stacking Aisle Width
72.1 (1831)
Free Lift
5.7
Performance
Lifting Speed - Full Load (fpm)
94
Lifting Speed - No Load (fpm)
134
Lowering Speed - Full Load (fpm)
104
Lowering Speed - No Load (fpm)
108
Drawbar Pull - Max. - Full Load (fpm)
2560
Drawbar Pull - Max. - No Load (fpm)
2540
Gradeability - Maximum - Full Load
27
Gradeability - Maximum - No Load
24
Maximum Travel Speed - Full Load (mph)
9.9
Maximum Travel Speed - No Load (mph)
10.2
Truck Weights
Weight Distribution - Full Load (lb.)
8320 / 1040
Weight Distribution - No Load (lb.)
3120 / 3240
Tires
Wheelbase (in.)
51.6
Tread Width (in.)
34.5 (36)
Underclearance -Center of Wheelbase (in.)
3.3
Brake - Service / Parking
Wet Disc (Foot) / Automatic (Electric)
Tread Width - Rear (in.)
6.9
Power System
Battery (5-hour rating) (V/Ah)
595 / 375
Battery Features
Battery Compartment Width (in.)
39.2
Battery Weight Minimum (lb.)
1543
Electric Motors - Drive (60 minutes) (hp)
4.8 x 2 x / 5 x 2
Control Type
MOSFET Transistor
