Specifications
General Data
Load Capacity (lbs./kgs.)
4000
Power Type
Battery
Tire Type
Cushion
Exterior Dimensions
Maximum Fork Height (MFH) (in.)
119.5
Free-Lift (in.)
5.9
Fork Size (T x W x L) (in.)
1.6 x 5 x 42
Tilt Range (deg)
5 / 6.5
Length to Fork Face (in.)
77.2
Overall Width (in.)
41.5
Mast Lowered Height (in.)
77.6
Mast Extended Height (in.)
167.7
Overhead Guard Height (in.)
81
Turning Radius (in.)
62.8
Load Distance (in.)
14.4
Basic Right-Angle Stacking Aisle Width (in.)
77.2 (1961)
Performance
Maximum Travel Speed - Full Load (mph)
9.7
Maximum Travel Speed - No Load (mph)
9.9
Lifting Speed - Full Load (fpm)
83
Lifting Speed - No Load (fpm)
134
Lowering Speed - Full Load (fpm)
104
Lowering Speed - No Load (fpm)
108
Drawbar Pull - Max. - Full Load (fpm)
2500
Drawbar Pull - Max. - No Load (fpm)
2520
Gradeability - Maximum - Full Load
22
Gradeability - Maximum - No Load
22
Truck Weights
Total Weight (lb.)
5400 (2450 without battery)
Weight Distribution - Full Load (front / rear) - (lb.)
10200 / 1300
Weight Distribution - No Load (front / rear) - (lb.)
3420 / 4080
Tires
Wheelbase (in.)
55.1
Tread Width - Front (in.)
34.5 (36)
Underclearance -Center of Wheelbase (in.)
3.3
Brake - Service / Parking
Wet Disc / Automatic
Tread Width - Rear (in.)
6.9
Power System
Battery (6-hour rating) (V/Ah)
660 / 770
Battery Features
Battery Compartment Width (in.)
39.2
Battery Weight Minimum (lb.)
2105
Electric Motors - Drive (60 minutes) (hp)
4.8 x 2 / 5 x 2
Control Type
MOSFET Transistor
