Features
Specifications
General Data
Power Type
Battery
Operator Position
Seated Rider
Tire Type
Solid Pneumatic
Wheels (x=driven)
2x / 2
Load Capacity (lbs./kgs.)
6000
Load Center
24 (600)
Auxiliary Hydraulic Function Specifications
Max. Operating Pressure (psi)
2300
Exterior Dimensions
Maximum Fork Height (MFH) (in.)
118
Free-Lift
5.3
Fork Size (T x W x L)
1.75 x 4.7 x 42
Fork Spread Max. / Min.
9.5 / 42
Tilt Range
6 / 11
Length to Fork Face
98
Overall Width
48.8
Mast Lowered Height
79.5
Mast Extended Height
166.1
Overhead Guard Height
86.4
Turning Radius
87
Load Distance
19.1
Basic Right-Angle Stacking Aisle Width
86
Performance
Lifting Speed - Full Load (fpm)
63
Lowering Speed - Full Load (fpm)
17 / 22
Lowering Speed - No Load (fpm)
11 / 19
Gradeability - Maximum - Full Load
11
Gradeability - Maximum - No Load
18
Maximum Travel Speed - Full Load (mph)
8.7
Truck Weights
Total Weight (lb.)
8135
Weight Distribution - Full Load (lb.)
15170 / 1830
Weight Distribution - No Load (lb.)
4610 / 5780
Tires
Number (front / rear)
2 / 2
Size - Front
28 x 9-15-14PR
Size - Rear
6.5-10-10PR
Wheelbase (in.)
65
Tread Width (in.)
39.8
Underclearance - Minimum with Load (in.)
4.5
Underclearance -Center of Wheelbase (in.)
5.5
Brake - Service / Parking
Hydraulic/ Hand
Tread Width - Rear (in.)
38
Power System
Battery (5-hour rating) (V/Ah)
80 / 370
Battery Min. Weight
2250
Battery Features
Electric Motors - Drive (60 minutes) (hp)
16
Control Type
Transistor Invertor
