Large Electric Forklift
8,000-12,000 lb. Lifting Capacity
Toyota's Large Electric Forklift gets the job done quietly and reliably. With 12,000 pounds of lifting power, this electric solution is ideal for any warehouse, including those in the food and beverage industries. This ruggedly designed counterbalance forklift has been built to withstand your toughest jobs while keeping the operator comfortable and productive.
Features
Specifications
For more detailed, product specific specification data, select an individual model number from the chart below.
| Model | Basic Right-Angle Stacking Aisle Width | Lifting Speed - Full Load (fpm) | Gradeability - Maximum - Full Load | Maximum Travel Speed - Full Load (mph) | Load Capacity (lbs./kgs.) |
|---|---|---|---|---|---|
| 7FBCU35 | 102.6 | 51.2 (36V), 72.9 (48 V) | 16 (36V), 22 (48V) | 8.4 (36V), 10.9 (48V) | 8000 |
| 7FBCU45 | 106.7 | 43 (36V), 57 (48V) | 13 (36V), 18 (48V) | 7.8 (36V), 10.9 (48V) | 10000 |
| 7FBCU55 | 116.9 | 37 (36V), 53 (48V) | 14 (36V), 20 (48V) | 7.5 (36V), 9.3 (48V) | 12000 |
Performance Data
Model
7FBCU35Basic Right-Angle Stacking Aisle Width
102.6
Lifting Speed - Full Load (fpm)
51.2 (36V), 72.9 (48 V)
Gradeability - Maximum - Full Load
16 (36V), 22 (48V)
Maximum Travel Speed - Full Load (mph)
8.4 (36V), 10.9 (48V)
Load Capacity (lbs./kgs.)
8000
Model
7FBCU45Basic Right-Angle Stacking Aisle Width
106.7
Lifting Speed - Full Load (fpm)
43 (36V), 57 (48V)
Gradeability - Maximum - Full Load
13 (36V), 18 (48V)
Maximum Travel Speed - Full Load (mph)
7.8 (36V), 10.9 (48V)
Load Capacity (lbs./kgs.)
10000
Model
7FBCU55Basic Right-Angle Stacking Aisle Width
116.9
Lifting Speed - Full Load (fpm)
37 (36V), 53 (48V)
Gradeability - Maximum - Full Load
14 (36V), 20 (48V)
Maximum Travel Speed - Full Load (mph)
7.5 (36V), 9.3 (48V)
Load Capacity (lbs./kgs.)
12000
