Features
Specifications
General Data
Power Type
Battery
Operator Position
Seated Rider
Tire Type
Cushion
Wheels (x=driven)
2x / 2
Load Capacity (lbs./kgs.)
8000
Auxiliary Hydraulic Function Specifications
Max. Operating Pressure (psi)
2630
Exterior Dimensions
Maximum Fork Height (MFH) (in.)
120
Free-Lift
4.3
Fork Size (T x W x L)
2 x 6 x 42
Tilt Range
5 / 6
Length to Fork Face
98.8
Overall Width
47.6
Mast Lowered Height
81.1
Mast Extended Height
168.1
Overhead Guard Height
91.9
Turning Radius
84.3
Load Distance
18.3
Basic Right-Angle Stacking Aisle Width
102.6
Performance
Lifting Speed - Full Load (fpm)
51.2 (36V), 72.9 (48 V)
Lifting Speed - No Load (fpm)
90.6 (36V), 118.1 (48V)
Lowering Speed - Full Load (fpm)
98
Lowering Speed - No Load (fpm)
108
Gradeability - Maximum - Full Load
16 (36V), 22 (48V)
Gradeability - Maximum - No Load
16 (36V), 22 (48V)
Maximum Travel Speed - Full Load (mph)
8.4 (36V), 10.9 (48V)
Maximum Travel Speed - No Load (mph)
9.3 (36V), 11.2 (48V)
Truck Weights
Total Weight (lb.)
10450
Weight Distribution - Full Load (lb.)
19350 / 2500
Weight Distribution - No Load (lb.)
5820 / 8030
Tires
Number (front / rear)
2 / 2
Size - Front
22 x 9 x 16
Size - Rear
18 x 6 x 12-1/8
Wheelbase (in.)
61.2
Tread Width (in.)
38.6
Underclearance - Minimum with Load (in.)
3.1
Underclearance -Center of Wheelbase (in.)
4.7
Brake - Service / Parking
Hydraulic / Hand
Tread Width - Rear (in.)
41.3
Power System
Battery (5-hour rating) (V/Ah)
36 / 1760, 48 / 1430
Battery Features
Electric Motors - Drive (60 minutes) (hp)
9.7 x 2
Control Type
Transistor Inverter / Chopper
