Features
Specifications
General Data
Bumper Height (in.)
9.75 (248)
Load Capacity (lbs./kgs.)
8000 (3632)
Power Type
Battery
Operator Position
Center-Controlled Rider
Tire Type
Rubber / Polyurethane
Wheels (x=driven)
1 Drive, 2 HD Casters / 2 Load
Exterior Dimensions
Overall Width (in.)
32.5 (826)
Basic Right-Angle Stacking Aisle Width (in.)
142
Fork Width (in.)
10 (254)
Lowered Height (in.)
3.25 (83)
Raised Height (in.)
9.25 (235)
Power Unit Height
31.4 (798)
Distance from Bumper to Center of Drive Tire (in.)
9.9 (251)
Bumper Underclearance (in.)
4.75 (121)
Performance
Maximum Travel Speed - Full Load (mph)
6.5 (10.5)
Maximum Travel Speed - No Load (mph)
9.0 (14.4)
Gradeability - Maximum - Full Load
8
Gradeability - Maximum - No Load
10
Tires
Number (front / rear)
3 / 2
Size - Front
12 x 4.75 (305 x 121)
Size - Rear
3.25 x 5.91 (83 x 150)
Tire Size - Casters (front) (in.)
4 x 2.5 (102 x 64)
Battery Features
Voltage/Capacity
24/750
Connector (Color)
SB-175 (gray)
Connector Cable Location
B
Connector Cable Length (in.)
18 (457)
Battery Compartment Width (in.)
31.5 (800)
Battery Weight Maximum (lb.)
1500 (680)
Battery Weight Minimum (lb.)
980 (445)
Electric Motors - Drive (60 minutes) (hp)
5.5 (4.1)
Control Type
Transistor / Contactor
