Features
Specifications
General Data
Power Type
Battery
Operator Position
Stand-Up (Center)
Tire Type
Rubber / Polyurethane
Wheels (x=driven)
1x / 2 / 2
Power Unit Height
35.3 (897)
Battery Roller (in.)
40-41 (1016-1041)
Load Capacity (lbs./kgs.)
6000 (2722)
Exterior Dimensions
Overall Width
33.3 (846)
Underclearance (lowered)
2.5 (63)
Base Legs Overall Width (OAW)
33.3 (846)
Platform Lift Height (in.)
46-47 (1168-1194)
Performance
Maximum Travel Speed - Full Load (mph)
9.0 (14.5)
Tires
Size - Front
12 x 4.75 (305 x 121)
Size - Rear
3.25 x 5.91 (83 x 150)
Brake - Service / Parking
Electric Disc Brake
Tire Size - Casters (front) (in.)
6 x 2 (152 x 51)
Power System
Battery Type
Lead-Acid
Battery Features
Voltage/Capacity
24 / 750
Battery Weight Maximum (lb.)
1500 (680)
Battery Weight Minimum (lb.)
980 (444)
Electric Motors - Drive (60 minutes) (hp)
5.5 (4.1)
