Specifications
General Data
Load Capacity (lbs./kgs.)
22000
Power Type
LP
Operator Position
Seated Rider / Center Seat
Tire Type
Cushion / Cushion
Wheels (x=driven)
2
Exterior Dimensions
Maximum Fork Height (MFH) (in.)
98.82
Free-Lift (in.)
0
Fork Size (T x W x L) (in.)
3 x7 x 48
Fork Spread Max. / Min. (in.)
50.31 / 15.66
Tilt Range (deg)
6/8
Length to Fork Face (in.)
135.76
Overall Width (in.)
60.72
Mast Lowered Height (in.)
98
Mast Extended Height (in.)
156.13
Overhead Guard Height (in.)
88.98
Turning Radius (in.)
118.50
Load Distance (in.)
25.80
Basic Right-Angle Stacking Aisle Width (in.)
144.30+Load
Performance
Maximum Travel Speed - Full Load (mph)
14.3
Maximum Travel Speed - No Load (mph)
14.3
Lifting Speed - Full Load (fpm)
46
Lifting Speed - No Load (fpm)
64
Lowering Speed - Full Load (fpm)
41
Lowering Speed - No Load (fpm)
35
Drawbar Pull - Max. - Full Load (fpm)
13102
Drawbar Pull - Max. - No Load (fpm)
7626
Gradeability - Maximum - Full Load
25.2
Gradeability - Maximum - No Load
44.9
Truck Weights
Total Weight (lb.)
29900
Weight Distribution - Full Load (front / rear) - (lb.)
48460 / 3440
Weight Distribution - No Load (front / rear) - (lb.)
12710 / 17190
Tires
Number (front / rear)
2 / 2
Size - Front
28 X 14 X 22
Size - Rear
22 X 8 X 16
Wheelbase (in.)
80
Tread Width - Front (in.)
46.25
Underclearance - Minimum with Load (in.)
3.80
Underclearance -Center of Wheelbase (in.)
4.30
Brake - Service / Parking
Hydraulic / Mechanical
Tread Width - Rear (in.)
47.82
Power System
Engine Make / Model
PSI V6 4.3L
Rated Horsepower @ rpm (SAE HP)
110 @ 2400
Rated Torque @ rpm (SAE HP)
230 @ 2400
Number of Cylinders
6
Transmission Type
PowerShift (Autoshift)
Transmission Speeds (forward / reverse)
3 / 3
Max. Operating Pressure (psi)
2250
Max. Flow Rate (gpm)
26.4
