Specifications
General Data
Load Capacity (lbs./kgs.)
90000 – 2 High / 90000– 3 High
Load Center
97
Power Type
Diesel
Operator Position
Seated Rider
Tire Type
Pneumatic
Wheels (x=driven)
4x / 2
Exterior Dimensions
Free-Lift (in.)
0
Tilt Range (deg)
5 / 10
Overall Width (in.)
172
Mast Lowered Height (in.)
257
Mast Extended Height (in.)
507
Overhead Guard Height (in.)
196
Turning Radius (in.)
320
Basic Right-Angle Stacking Aisle Width (in.)
522
Performance
Maximum Travel Speed - Full Load (mph)
19.2
Maximum Travel Speed - No Load (mph)
19.2
Lifting Speed - Full Load (fpm)
47
Lifting Speed - No Load (fpm)
50
Lowering Speed - Full Load (fpm)
60
Lowering Speed - No Load (fpm)
60
Drawbar Pull - Max. - Full Load (fpm)
26572
Drawbar Pull - Max. - No Load (fpm)
28372
Gradeability - 1 mph - Full Load
7.1
Gradeability - Maximum - Full Load
11.5
Gradeability - Maximum - No Load
18.4
Truck Weights
Total Weight (lb.)
168578
Weight Distribution - Full Load (front / rear) - (lb.)
225851 / 32727
Weight Distribution - No Load (front / rear) - (lb.)
90470 / 78108
Tires
Number (front / rear)
4 / 2
Size - Front
18.00-25-40PR
Size - Rear
18.00-25-40PR
Wheelbase (in.)
236
Tread Width - Front (in.)
120
Underclearance - Minimum with Load (in.)
16
Underclearance -Center of Wheelbase (in.)
21
Brake - Service / Parking
Wet Disc / Caliper
Tread Width - Rear (in.)
105
Power System
Battery (6-hour rating) (V/Ah)
12V
Piston Displacement (cu in)
660
Fuel Tank Capacity (US gal)
155
Engine Make / Model
CUMMINS 8.9L QSL9
Rated Horsepower @ rpm (SAE HP)
380 @ 2100
Rated Torque @ rpm (SAE HP)
1201 @ 1500
Number of Cylinders
6
Transmission Type
PowerShift (Autoshift)
Transmission Speeds (forward / reverse)
3 / 3
Auxiliary Hydraulic Function Specifications
Max. Operating Pressure (psi)
3125
