Specifications
General Data
Load Capacity (lbs./kgs.)
8000 (3500)
Load Center
24 (600)
Power Type
Battery (90V)
Operator Position
Seated Rider
Tire Type
Pneumatic
Wheels (x=driven)
2x / 2
Exterior Dimensions
Maximum Fork Height (MFH) (in.)
120 (3050)
Free-Lift (in.)
4.3 (110)
Fork Size (T x W x L) (in.)
2x6x42 (50x150x1070)
Fork Spread Max. / Min. (in.)
12/45.5
Tilt Range (deg)
6/12
Length to Fork Face (in.)
115 (2920)
Overall Width (in.)
54.1 (1375)
Mast Lowered Height (in.)
83.2 (2115)
Mast Extended Height (in.)
168 (4270)
Overhead Guard Height (in.)
88.5 (2250)
Turning Radius (in.)
103.5 (2630)
Load Distance (in.)
20 (505)
Basic Right-Angle Stacking Aisle Width (in.)
123.5 (3135)
Performance
Maximum Travel Speed - Full Load (mph)
14.1 (22.5)
Maximum Travel Speed - No Load (mph)
14.8 (24)
Lifting Speed - Full Load (fpm)
105 (535)
Lifting Speed - No Load (fpm)
110 (560)
Lowering Speed - Full Load (fpm)
94 (475)
Lowering Speed - No Load (fpm)
95 (480)
Drawbar Pull - Max. - Full Load (fpm)
1910 (870)
Drawbar Pull - Max. - No Load (fpm)
2100 (950)
Gradeability - Maximum - Full Load
9.6 (17)
Gradeability - Maximum - No Load
12.9 (23)
Truck Weights
Total Weight (lb.)
13430 (6090)
Weight Distribution - Full Load (front / rear) - (lb.)
18340 / 2800
Weight Distribution - No Load (front / rear) - (lb.)
6130 / 7300
Tires
Number (front / rear)
2 / 2
Size - Front
250-15-18PR
Size - Rear
7-12-12PR
Wheelbase (in.)
74.8 (1900)
Tread Width - Front (in.)
43.9 (1115)
Underclearance - Minimum with Load (in.)
4.9 (125)
Underclearance -Center of Wheelbase (in.)
7.7 (195)
Brake - Service / Parking
Hydraulic/ Auto-Electric
Tread Width - Rear (in.)
43.3 (1100)
Battery Features
Voltage/Capacity
88.8/564
