Features
Specifications
General Data
Load Capacity (lbs./kgs.)
3000 (1360)
Load Center
24 (600)
Power Type
Battery (24V)
Operator Position
Stand-Up Rider
Tire Type
Polyurethane
Wheels (x=driven)
1x / 4
Exterior Dimensions
Fork Size (T x W x L) (in.)
1.5 x 4 x 42 (38 x 102 x 1067)
Length to Fork Face (in.)
74 (1880)
Overall Width (in.)
40-60
Overhead Guard Height (in.)
88.25 (2242)
Turning Radius (in.)
72.15 (1833)
Power Unit Width
40 (1016)
Power Unit Height
47 (1194)
Base Legs Overall Width (OAW)
40-60 (1015-1524)
Platform Height (in.)
7 (178)
Performance
Maximum Travel Speed - Full Load (mph)
6.5
Maximum Travel Speed - No Load (mph)
6.5
Lifting Speed - Full Load (fpm)
57
Lifting Speed - No Load (fpm)
90
Lowering Speed - Full Load (fpm)
92
Lowering Speed - No Load (fpm)
70
Max carrying load
313
Tires
Number (front / rear)
1 / 4
Wheelbase (in.)
60 (1524)
Underclearance -Center of Wheelbase (in.)
2 (51)
Brake - Service / Parking
Electronic Disc Brake
Grade Clearance (%)
13
Power System
Battery (6-hour rating) (V/Ah)
24/ 1085
