Features
Specifications
General Data
Power Type
Battery
Operator Position
Walkie
Tire Type
Polyurethane
Wheels (x=driven)
1 Drive / 2 Casters / 4 Load Wheels
Load Capacity (lbs./kgs.)
3500 (1588)
Exterior Dimensions
Maximum Fork Height (MFH) (in.)
207 (5280)
Fork Size (T x W x L)
1.6x4.7x45.3 (41x119x1150)
Length to Fork Face
36.4 (925)
Mast Lowered Height
83 (2108)
Mast Extended Height
200.3 (5088)
Turning Radius
61 (1550)
Basic Right-Angle Stacking Aisle Width
96 (2439)
Underclearance (lowered)
1.6 (40)
Power Unit Width
32.1 (816)
Power Unit Height
56 (1423)
Performance
Lifting Speed - Full Load (fpm)
25.59 (130)
Lifting Speed - No Load (fpm)
35.43 (180)
Lowering Speed - Full Load (fpm)
39.37 (200)
Lowering Speed - No Load (fpm)
27.56 (140)
Gradeability - Maximum - Full Load
6
Gradeability - Maximum - No Load
12
Maximum Travel Speed - Full Load (mph)
3.4 (5.4)
Maximum Travel Speed - No Load (mph)
3.7 (6)
Truck Weights
Weight Distribution - Full Load (lb.)
1823.2 / 4967 (827 / 2253)
Weight Distribution - No Load (lb.)
1904.8 / 1358 (864 / 616)
Tires
Size - Front
8.27 x 2.95 (210 x 75)
Size - Rear
3.94 x 1.57 (100 x 40)
Wheelbase (in.)
54.3 (1380)
Brake - Service / Parking
Electric Disc Brake
Tire Size - Casters (front) (in.)
3.31 x 2.76 (84 x 70)
Power System
Battery (5-hour rating) (V/Ah)
24 / 270
Battery Features
Control Type
AC / DC Control
