Features
Specifications
General Data
Load Capacity (lbs./kgs.)
3000 (1361)
Load Center
24 (600)
Power Type
Battery
Operator Position
Walkie
Tire Type
Rubber / Polyurethane
Wheels (x=driven)
1x / 2 / 4
Exterior Dimensions
Maximum Fork Height (MFH) (in.)
189 (4800)
Free-Lift (in.)
6 (153)
Fork Size (T x W x L) (in.)
1.5 x 4 x 42 (40 x 100 x 1067)
Length to Fork Face (in.)
44.4 (1128)
Mast Lowered Height (in.)
87 (2210)
Mast Extended Height (in.)
237 (6020)
Turning Radius (in.)
64.9 (1648)
Basic Right-Angle Stacking Aisle Width (in.)
88
Lowered Height (in.)
2 (51)
Power Unit Width
32.5 (826)
Power Unit Height
34 (864)
Base Legs Overall Width (OAW)
4 (101)
Performance
Maximum Travel Speed - Full Load (mph)
3.5 (5.6)
Maximum Travel Speed - No Load (mph)
3.5 (5.6)
Lifting Speed - Full Load (fpm)
32 (163)
Lifting Speed - No Load (fpm)
49 (249)
Lowering Speed - Full Load (fpm)
60 (305)
Lowering Speed - No Load (fpm)
42 (213)
Gradeability - Maximum - Full Load
6
Gradeability - Maximum - No Load
10
Tires
Size - Front
12 x 4.5 (305 x 114)
Size - Rear
4 x 2.875 (102 x 73)
Underclearance -Center of Wheelbase (in.)
2.1 (53)
Brake - Service / Parking
Regenerative
Tire Size - Casters (front) (in.)
4 x 2.5 (102 x 64)
Power System
Battery (6-hour rating) (V/Ah)
24 (654)
Battery Features
Battery Compartment Width (in.)
13.38 (340)
Battery Weight Minimum (lb.)
950 (431)
Capacity List
Wheelbase (in.)
55.1 (1400)
