    Core IC Pneumatic Forklift

    3,000-6,500 lb. Lifting Capacity

    Dependable, durable, and engineered with ergonomics in mind, the Core IC Pneumatic counterbalance forklift can maneuver nearly any typical material handling load. With a lift capacity range of 3,000–6,500 lbs., the Toyota Core IC Pneumatic forklift is the premier material handling solution for most outdoor applications. Additionally, this lift comes equipped with high-performance pneumatic tires that provide a reassuringly strong grip on uneven surfaces. Get ready to get stuff done.

    Apply For Financing Request A Quote
    Request Rental Quote

    Features

    Visibly Better

    Forward, up, back. Whichever way you look, you'll appreciate the clear, open sight lines of the Core IC Pneumatic Counterbalance Forklift. The mast hose is hidden, the top skid bars are oriented for maximum visibility, and the mast crossmember does not block the view of the fork tips. The standard multifunction LCD display, conveniently located on the dashboard, features QR code diagnostics for easy access to operational and performance data.
    Key Security Features

    The safety features of the Core IC air lift include Active Mast Control (AMC), which responds automatically to improve the stability of cables handled at high lifting heights. This forklift also includes the Active Stability System (SAS), ™ which automatically detects potentially unsafe conditions and activates additional safety features to increase operator protection and reduce damage to the product and forklift. One-way fork auto-leveling: Leveled forks parallel to the ground from a tilt-back position at the push of a button.
    Serviceability

    Toyota forklifts are built with the finest components and meticulously planned integrated systems that deliver intuitive and reliable performance on a daily basis. Toyota forklifts don't usually require service, but when they do, it's quick and easy, by design. Toyota's legendary quality means more productivity throughout the lifecycle of your forklift, along with lower repair costs. The Core IC pneumatic forklift offers several service features. These features include an easy-to-access, tool-free floor platform, locking engine hood assist damper, and externally mounted hydraulic oil return filter.

    Built for Bigger Jobs, Longer Days

    Toyota’s Core IC Pneumatic Forklift is built for operations that demand power, durability, and all-day performance. Offering fast travel speeds, high torque, and exceptional lifting strength, it delivers the productivity needed to tackle the toughest outdoor jobs. With a larger fuel tank that supports longer runtimes between refueling, this forklift keeps your operation moving without unnecessary downtime. Its rugged pneumatic tires provide enhanced grip on uneven surfaces, while its durable construction stands up to harsh conditions. More power for heavy loads, more stability on rough terrain, and more capability to handle your entire outdoor to-do list—whatever the challenge, the Toyota Core IC Pneumatic is ready for it.

    Specifications

    For more detailed, product specific specification data, select an individual model number from the chart below.

    Model Load Capacity (lbs./kgs.) Maximum Travel Speed - Full Load (mph) Lifting Speed - Full Load (fpm) Gradeability - Maximum - Full Load Basic Right-Angle Stacking Aisle Width (in.)
    40-8FGU15 3000 11.5 131 45 91.9 (2335)
    40-8FGU18 3500 11.5 131 45 93.9
    40-8FGU20 4000 11.2 / 10.9 117 43% 109.4
    40-8FGU25 5000 10.9 118 31/33 105.9
    40-8FGU30 6000 11.2 98 25/26 111.6
    40-8FGU32 6500 11.2 98 25/26 112.4
    50-8FGU15 3000 11.5 131 45 91.9
    50-8FGU18 3500 11.5 131 45 93.9
    50-8FGU20 4000 10.9 118 39 103.2
    50-8FGU25 5000 10.9 118 33 105.9
    50-8FGU30 6000 11.2 100 25 111.6
    50-8FGU32 6500 11.2 100 24 112.4

    Performance Data

    Model

    40-8FGU15

    Load Capacity (lbs./kgs.)

    3000

    Maximum Travel Speed - Full Load (mph)

    11.5

    Lifting Speed - Full Load (fpm)

    131

    Gradeability - Maximum - Full Load

    45

    Basic Right-Angle Stacking Aisle Width (in.)

    91.9 (2335)

    Model

    40-8FGU18

    Load Capacity (lbs./kgs.)

    3500

    Maximum Travel Speed - Full Load (mph)

    11.5

    Lifting Speed - Full Load (fpm)

    131

    Gradeability - Maximum - Full Load

    45

    Basic Right-Angle Stacking Aisle Width (in.)

    93.9

    Model

    40-8FGU20

    Load Capacity (lbs./kgs.)

    4000

    Maximum Travel Speed - Full Load (mph)

    11.2 / 10.9

    Lifting Speed - Full Load (fpm)

    117

    Gradeability - Maximum - Full Load

    43%

    Basic Right-Angle Stacking Aisle Width (in.)

    109.4

    Model

    40-8FGU25

    Load Capacity (lbs./kgs.)

    5000

    Maximum Travel Speed - Full Load (mph)

    10.9

    Lifting Speed - Full Load (fpm)

    118

    Gradeability - Maximum - Full Load

    31/33

    Basic Right-Angle Stacking Aisle Width (in.)

    105.9

    Model

    40-8FGU30

    Load Capacity (lbs./kgs.)

    6000

    Maximum Travel Speed - Full Load (mph)

    11.2

    Lifting Speed - Full Load (fpm)

    98

    Gradeability - Maximum - Full Load

    25/26

    Basic Right-Angle Stacking Aisle Width (in.)

    111.6

    Model

    40-8FGU32

    Load Capacity (lbs./kgs.)

    6500

    Maximum Travel Speed - Full Load (mph)

    11.2

    Lifting Speed - Full Load (fpm)

    98

    Gradeability - Maximum - Full Load

    25/26

    Basic Right-Angle Stacking Aisle Width (in.)

    112.4

    Model

    50-8FGU15

    Load Capacity (lbs./kgs.)

    3000

    Maximum Travel Speed - Full Load (mph)

    11.5

    Lifting Speed - Full Load (fpm)

    131

    Gradeability - Maximum - Full Load

    45

    Basic Right-Angle Stacking Aisle Width (in.)

    91.9

    Model

    50-8FGU18

    Load Capacity (lbs./kgs.)

    3500

    Maximum Travel Speed - Full Load (mph)

    11.5

    Lifting Speed - Full Load (fpm)

    131

    Gradeability - Maximum - Full Load

    45

    Basic Right-Angle Stacking Aisle Width (in.)

    93.9

    Model

    50-8FGU20

    Load Capacity (lbs./kgs.)

    4000

    Maximum Travel Speed - Full Load (mph)

    10.9

    Lifting Speed - Full Load (fpm)

    118

    Gradeability - Maximum - Full Load

    39

    Basic Right-Angle Stacking Aisle Width (in.)

    103.2

    Model

    50-8FGU25

    Load Capacity (lbs./kgs.)

    5000

    Maximum Travel Speed - Full Load (mph)

    10.9

    Lifting Speed - Full Load (fpm)

    118

    Gradeability - Maximum - Full Load

    33

    Basic Right-Angle Stacking Aisle Width (in.)

    105.9

    Model

    50-8FGU30

    Load Capacity (lbs./kgs.)

    6000

    Maximum Travel Speed - Full Load (mph)

    11.2

    Lifting Speed - Full Load (fpm)

    100

    Gradeability - Maximum - Full Load

    25

    Basic Right-Angle Stacking Aisle Width (in.)

    111.6

    Model

    50-8FGU32

    Load Capacity (lbs./kgs.)

    6500

    Maximum Travel Speed - Full Load (mph)

    11.2

    Lifting Speed - Full Load (fpm)

    100

    Gradeability - Maximum - Full Load

    24

    Basic Right-Angle Stacking Aisle Width (in.)

    112.4
