Features
Specifications
General Data
Load Capacity (lbs./kgs.)
6000
Power Type
Gasoline / LP
Operator Position
Seated Rider
Tire Type
Pneumatic
Wheels (x=driven)
2x / 2
Exterior Dimensions
Maximum Fork Height (MFH) (in.)
131.5
Free-Lift (in.)
5.3
Fork Size (T x W x L) (in.)
1.8 x 5 x 42
Fork Spread Max. / Min. (in.)
42 / 10
Tilt Range (deg)
6 / 11
Length to Fork Face (in.)
109.4
Overall Width (in.)
48.8
Mast Lowered Height (in.)
85.3
Mast Extended Height (in.)
179.7
Overhead Guard Height (in.)
85.5
Turning Radius (in.)
7.48 / 92.5
Load Distance (in.)
19.1
Rear Overhang (in.)
23
Basic Right-Angle Stacking Aisle Width (in.)
111.6
Performance
Maximum Travel Speed - Full Load (mph)
11.2
Maximum Travel Speed - No Load (mph)
11.5
Lifting Speed - Full Load (fpm)
98
Lifting Speed - No Load (fpm)
102
Lowering Speed - Full Load (fpm)
98
Lowering Speed - No Load (fpm)
98
Drawbar Pull - Max. - Full Load (fpm)
4280 / 4390
Drawbar Pull - Max. - No Load (fpm)
2310
Gradeability - Maximum - Full Load
25/26
Gradeability - Maximum - No Load
21
Truck Weights
Total Weight (lb.)
9450
Weight Distribution - Full Load (front / rear) - (lb.)
13370 / 2080
Weight Distribution - No Load (front / rear) - (lb.)
3510 / 5940
Tires
Number (front / rear)
2 / 2
Size - Front
28 x 9-15-12PR
Size - Rear
6.5-10-10PR
Wheelbase (in.)
66.9
Tread Width - Front (in.)
39.8
Underclearance - Minimum with Load (in.)
4.5
Underclearance -Center of Wheelbase (in.)
7.3
Brake - Service / Parking
Hydraulic / Mechanical
Tread Width - Rear (in.)
38
Power System
Battery (6-hour rating) (V/Ah)
12 / 35
Piston Displacement (cu in)
151
Fuel Tank Capacity (US gal)
15.9
Engine Make / Model
Kubota/WG2503
Rated Horsepower @ rpm (SAE HP)
56@2600 / 58@2600
Rated Torque @ rpm (SAE HP)
122@1800 / 129@1600
Number of Cylinders
4
Transmission Type
Powershift
Transmission Speeds (forward / reverse)
1 / 1
Max. Operating Pressure (psi)
2275
Max. Flow Rate (gpm)
21
