Features
Specifications
General Data
Load Capacity (lbs./kgs.)
4500 (2043
Load Center
24 (600)
Power Type
Battery
Operator Position
Stand-Up Rider
Tire Type
Polyurethane
Wheels (x=driven)
1x / 1 / 4
Exterior Dimensions
Maximum Fork Height (MFH) (in.)
268
Free-Lift (in.)
69
Fork Size (T x W x L) (in.)
1.75 x 4 x 42
Fork Spread Max. / Min. (in.)
24 - 48 (610 - 1219)
Tilt Range (deg)
3 / 4.5
Overall Width (in.)
31 (787)
Mast Lowered Height (in.)
118 (2997)
Mast Extended Height (in.)
304 (7722)
Turning Radius (in.)
84.5 (2146)
Lowered Height (in.)
3 (76)
Power Unit Width
42.5 (1080)
Power Unit Height
51.5 (1308)
Base Legs Overall Width (OAW)
10 / 12 (254 / 305)
Performance
Maximum Travel Speed - Full Load (mph)
7 (11.3)
Gradeability - Maximum - Full Load
7
Truck Weights
Total Weight (lb.)
5650
Tires
Number (front / rear)
1x / 1 / 4
Size - Front
13.5 x 6 (343 x 152)
Size - Rear
8 x 4 (203 x 102)
Underclearance -Center of Wheelbase (in.)
2 (51)
Brake - Service / Parking
Electronic Disc Brake
Tire Size - Casters (front) (in.)
8 x 4 (203 x 102)
Power System
Battery Type
Lead Acid
Battery Features
Voltage/Capacity
36 / 1240
Battery Compartment Width (in.)
18.2 (463)
Battery Weight Maximum (lb.)
2300 (1043)
Battery Weight Minimum (lb.)
2600 (1179)
Electric Motors - Drive (60 minutes) (hp)
7.1 (5.3)
Control Type
AC
